Available Size
Pulley Diameter 200mm~1800mm
Pulley Length 400mm~3200mm
Key Features
|
Feature |
Benefit |
|
Wide size range |
Diameter 200-1800mm, length 400-3200mm |
|
Multiple pulley types |
Drive, return, snub, take-up, bend, idler |
|
Full accessory line |
Lagging, shafts, bearings, discs, flanges |
|
Essential for belt tracking |
Improves conveyor reliability |
Pulley Types By Position & Application
|
Type |
Function |
|
Drive / Head Pulley |
Provides driving force to the conveyor belt |
|
Return / Tail Pulley |
Redirects belt at the return end |
|
Snub Pulley |
Increases belt wrap angle around drive pulley |
|
Take-Up Pulley |
Maintains proper belt tension |
|
Bend Pulley |
Changes belt direction |
|
Idler Pulley |
Supports belt and material load |
Available Accessories
|
Accessory |
Function |
|
Pulley Lagging |
Increases friction between pulley and belt |
|
Step Shaft |
Provides mounting and torque transmission |
|
Forged Bar |
Shaft material option |
|
Ring / End Disc / Flange |
Pulley end construction components |
|
Bearing Housing |
Supports shaft rotation |
|
Adapter Sleeve |
Mounts bearings to shaft |
|
Withdrawal Sleeve |
Facilitates bearing removal |
